How it Works

Tensor subclass and eager mode

When you do:

a = torch.randn((2, 2), device='jax')
print(a)
print(type(a))

It will say that a is an instance of torchax.tensor.Tensor class.

The class torchax.tensor.Tensor is a subclass of torch.Tensor. It overrides __torch_dispatch__ properly so that regular PyTorch operators, such as torch.matmul, to work as expected.

It roughly looks like this (with some details removed):

The complete class impl is at tensor.py

class Tensor(torch.Tensor):

    @staticmethod
    def __new__(cls, elem):
        return torch.Tensor._make_wrapper_subclass(
            cls,
            shape,
            dtype=dtype,
            device='meta',
            requires_grad=False,
        )

    def __init__(self, elem: jax.Array):
        super().__init__()
        self._elem = elem

    __torch_function__ = torch._C._disabled_torch_function_impl

    @classmethod
    def __torch_dispatch__(cls, func, types, args=(), kwargs=None):
        # here assumes ALL tensors in args / kwargs are
        # instances of Tensor
        args, kwargs = unwrap((args, kwargs))
        jax_func = some_registry[func]
        res = jax_func(*args, **kwargs)
        return wrap(res)

    def wrap(tree):
        # wrap jax.Array with Tensor
        return pytree.tree_map_only(
            jax.Array, Tensor, tree)

    def unwrap(tree):
        # get jax.Array out ofTensor
        return pytree.tree_map_only(
            Tensor, lambda x: x._elem, tree)

In other words, assuming that we have a function that takes jax.Array as input and returns jax.Array but otherwise implement the same semantics as a [ATen]{.title-ref} op; then, using this tensor we would be able to route the call to this jax function.

The jaten.py file defines some of those ops.

Let\'s take aten::matmul as example:

@op(torch.ops.aten.matmul)
def _aten_matmul(x, y):
    return jnp.matmul(x, y)

The @op decorator just puts this function into some_registry dictionary.

_aten_add has same signature as torch.ops.aten.add but takes jax.Array as input.

Now, when torch.matmul is called; we will get the information and swap it to a JAX version of that function.

In otherwords, because our tensor subclass implements all the operators that PyTorch has, thus, a PyTorch model cannot tell a difference because it and regular CPU tensor. ( In other words, our subclass obeys the Liskov Substitution Principle).

Therefore, when a Pytorch Model (torch.nn.Module) receives our special tensor, it will do math on it without knowing that we sneaked in a jax.Array.

NOTE: This mechanism of using a Python numerical library as a PyTorch backend is not JAX specific. Here is an example here Apple MLX is used as a PyTorch backend the same way: https://github.com/qihqi/tnt
