Automotive Design for Compose

Automotive Design for Compose (also called DesignCompose in the source) is an extension to Jetpack Compose that allows every screen, component, and overlay of your Android App to be defined in Figma, and lets you see the latest changes to your Figma design in your app, immediately!

To use Automotive Design for Compose in an app, a developer specifies the Composables that they’d like to be defined by Figma, and a designer uses Figma to draw them. Most Figma features, including Auto Layout, Interactions, Variants, and Blend Modes are fully supported. This repo includes the DesignCompose library, an interactive tutorial app (in reference-apps/Tutorial), and a sample customizable Media Center for Android Automotive OS (in reference-apps/aaos-unbundled).

Impact on the design development flow

A primary goal of DesignCompose is to improve the design and development of user interfaces. With DesignCompose, you can incorporate testing, corrections, and even large-scale changes into any part of the development process.

Typically, an OEM UI development process is linear. Product managers and designers start by defining functionality and creating UI mockups. Then engineers implement UI mockups. At this point, an engineer implements and tests the UI in a car. However, since testing occurs late in the development cycle, it’s difficult and costly to make changes.

DesignCompose lets you incorporate design tools into the UI development cycle to create and visualize designs in real time.

  1. Enables development of all aspects of a UI across apps and display modes.

  2. Provides tools to create customized UI experiences for vehicles. Support new brands without writing new code.

  3. Allows rapid and regular software updates across a fleet of vehicles, for all brands and configurations, including UIs with different interaction models.

  4. Enables development teams to revise designs late in the software-development cycle. Teams can test designs in vehicles, immediately after each UI change.

DesignCompose allows teams to develop iterative and non-linear development workflows. The following are some example workflows and use cases.

  1. When new functionality is first exposed, these tasks must be completed:

    • Product managers and designers start by defining functionality and then creating UI designs in Figma (including UI navigation and interactions) using the built-in prototyping and Interactive Components capabilities.

    • Engineers use DesignCompose to create Jetpack Compose components from the Figma design, defining “#keywords” that are used by the Figma document to express where data is to be displayed.

    • Designers can continue to iterate on their Figma documents until the design is complete and agreed upon.

    • Design artifacts can be built into the target app for deployment to production.

  2. When creating new designs for additional brands and display configurations, designers can create new designs in Figma, using the #keywords already defined.
