Synchronous Procs in XLS
Proposal
This document proposes an alternate implementation of procs based on synchronous data flow, a restriction of Kahn process networks where the communication behavior over channels is known statically. This synchronous implementation, accomplished via changes to scheduling and codegen, offers a number of usability and QoR advantages relative to our current asynchronous implementation:
- Channel flow control (ready and valid signals) and the associated logic can be eliminated. This improves QoR and avoids combinational cycles which can occur when developing networks of procs.
- The throughput of the proc network can be guaranteed by the scheduler rather than relying on the user to coordinate the relative timing of sends and receives across procs to achieve a target throughput and avoid deadlocks.
- Under certain conditions channels can be replaced with wires enabling scheduling stages to span proc boundaries which increases scheduling flexibility and can improve QoR (latency and area).
Conceptually, synchronous procs are scheduled together into a single pipeline rather than as separate communicating pipelines. Little or no changes to the DSLX code are necessary and behavior is preserved relative to the asynchronous implementation excepting scheduling dependent ordering and quirks in the existing codegen implementation.
Synchronous data flow requires that channel communication is known statically. In the XLS context this means that the predicates of send and receive operations are predictable (specific conditions are detailed below). A simple, sufficient condition is that all sends and receives are un-predicated. This document focuses on this case although relaxation of this constraint is likely possible. A further simplification assumed here (again, likely relaxable) is that all procs have an initiation interval of one, i.e. full throughput.
Under these two conditions the scheduling of the nodes of the network of procs can be formulated as a single global scheduling problem. The scheduler statically resolves the relative timing of sends and receives without the need for channel flow control and ensures full throughput. The scheduling problem can be formulated as follows:
- All nodes of all procs are collectively scheduled in a single formulation.
- Feed-forward channels are treated as regular data flow edges similar to an edge between nodes within a proc or function.
- Send and receive nodes of loopback channels[^1] require scheduling constraints specifying a maximum schedule distance between the nodes. The schedule distance must be less than the number of initial values in the channel to guarantee full throughput.
The nodes of all of the procs along with the edges defined by channels is the global data flow graph. The scheduler operates on the global data flow graph and assigns a global stage number to every node. To generate pipelines for each proc, the global stage number is mapped to a proc-relative stage number by subtracting the earliest global stage of any node in the proc. These proc-relative stage numbers are used by codegen to generate the proc pipeline as with the existing codegen. Unlike existing codegen, no channel flow control logic needs to be generated. Stage activation logic can be simplified to a feed-forward valid signal (the case is more complicated if the synchronous system can stall, see below)
Feed-forward channels are implemented as wires or a sequence of one or more registers depending on the schedule distance between the send and receive nodes. If scheduled in the same global stage, the channel is a wire. If scheduled in different stages the channel is implemented as a sequence of pipeline registers (the send is necessarily scheduled before the receive as this is a feed-forward channel). This is identical to the way regular node-to-node dataflow edges are handled. loopback channels are implemented as a FIFO with one or more initial values.
As in the asynchronous case, the proc pipelines are instantiated hierarchically and connected by the respective channel implementations (wires, registers, or FIFOs) to produce the synchronous implementation.
Example
Consider a simple proc hierarchy where a top-level proc A instantiates two subprocs B and C. The internal logic of the procs is abstracted away and only the channel communication is shown. Channels IN and OUT are input/output channels of the design. Channels B2C and C2B are for interproc communication and channel LB is a loopback channel. The procs may be stateful or stateless.
Similar to the case of scheduling (pipelining) a single function or proc, the location of pipeline registers can be represented as cuts through the data flow graph. In the case of synchronous procs, these cuts extend through the global data flow graph and potentially cut across multiple procs. In the example, the following might be a possible schedule of the design with pipeline register locations shown as red lines:
The design is pipelined into five stages separated by four sets of pipeline registers.
Similar to normal dataflow edges, if a channel edge spans a pipeline boundary a pipeline register is introduced. For example, channel B2C is represented as a register. However, channel C2B which does not span a boundary is represented as a wire. A channel edge could also span multiple pipeline boundaries in which case the channel would be represented with multiple registers.
The loop back channel LB is represented as a single register with a reset value equal to the initial value of the channel. If the channel requires multiple initial values because it spans multiple cycles then an initial constraint on the implementation could be that all initial values must be the same (which becomes the reset value of the register representing the channel).
Non-channel nodes are handled as in the single proc/function case. In the above example, non-channel nodes may appear in any of the stages.
Behavior vs asynchronous implementation
Systems of synchronous procs produce the same results (ie, values written on output channels) as asynchronously implemented procs[^2] because the synchronous data flow model is just a specialization of Kahn process networks and has the same deterministic result guarantees. However, the specific timing of send and receive operations may be different. The specific send and receive operations whose executions are tied together may also differ. For the simple case of full throughput with un-predicated send and receives the bundling and ordering of operations is immaterial as all sends and receives execute every cycle excepting pipeline ramp-up.
Comparison vs single proc implementation with functions
Any hierarchy of procs can be implemented as a single proc[^3] with composition and reuse handled via function invocation. In the current XLS flow, all function invocations are inlined so some of the benefits of synchronous procs can be captured with function invocation:
- Feed-forward channels in the multi-proc design become regular node-to-node data flow edges in the single-proc design so there is no internal flow control and these edges need not align with cycle boundaries.
- Proc throughput is guaranteed by the scheduler. The user does not need to coordinate channel communication across procs as this communication becomes regular data flow edges in a single proc design.
Implementing the design as a single proc with functions also has at least one advantage over synchronous procs which is the scope of existing analyses and optimizations is the entire design after function inlining.
However, implementing the design as a single proc also has some notable disadvantages:
- Some subcomponents of the design may more naturally be represented as procs with state and/or channel communication. In a single proc design, state and channel communication must be hoisted to the top level.
- The design hierarchy is flattened and the entire design becomes a single (potentially very large) RTL module. This may be detrimental to downstream flows such as DV and PD[^4] as well as adversely affecting the readability of the RTL in general.
- All of the code being in a single unit can cause XLS toolchain scaling problems. This can cause unacceptably slow analysis, optimization, and other processes such as LLVM JIT compilation. Some of the current implementations of these processes (such as the block JIT) do not take advantage of a hierarchically decomposed design but that is a current implementation limitation and something we may wish to fix in the future.
Some of these drawbacks might be mitigated by not inlining all functions and handling function invocation all the way through codegen.
Extensions and generalizations
Initiation interval greater than one
The simplest generalization beyond full throughput is all procs having the same initial interval which is greater than one. In this case, loopback channel constraints (the number of required initial values) may change, but the global scheduling formulation should work without modification. A more complicated generalization is a mixed initiation interval design. The details of this generalization are TBD.
Predicated sends and receives
A relatively easy generalization allowing some predication is if the send and receive operation on a particular channel always have identical predicate values for the same activation[^5]. That is, the send fires if and only if the receive fires. This could be checked statically for simple cases or checked dynamically via asserts. In this case, no changes are needed to the implementation described above.
Supporting cases where the send and receive predicates can be different is more complicated. Because there is no flow control the writing and reading of values to the channel must be precisely orchestrated to avoid losing data. This is a hard problem in general to analyse across the stateful evolution of the system but might be possible for special cases.
Multiply instantiated procs
Multiply instantiated procs pose complications for scheduling because the schedule of the proc must satisfy the scheduling constraints at each point at which it is instantiated. For some common situations such as a proc which is instantiated multiple times in parallel the additional constraints may be easy to satisfy. For more complicated situations, the proc can be cloned to avoid multiple instantiations.
Pipeline flow control
The synchronous implementation as described above has no flow control. The implementation expects all inputs to the design to be valid and all outputs to be ready every cycle. This enables unconditional, full-throughput execution. These constraints on input valid / output ready can be relaxed if pipeline flow control (e.g., bubble flow control) is added to the synchronous implementation. This eases the incorporation of the synchronous implementation into asynchronous systems because the pipeline will stall if no input is available and backpressure if unable to write outputs.
The logic for pipeline flow control for the global pipeline in the synchronous system is the same as for the pipeline of a single proc or function in the existing XLS implementation. The difference in the synchronous system of procs is that a stage can span multiple procs so wiring the flow control logic is more complicated. This is not theoretically difficult but requires additional work in codegen.
Synchronous procs within asynchronous system of procs
If a synchronous system of procs has pipeline flow control, then the system of procs can be embedded within a larger system of asynchronous procs. Conceptually, this results in a synchronous domain within an asynchronous domain. The execution of send and receive operations which are scheduled in the same global stage (potentially in different procs) will be bundled together similar to the way these operations are bundled within a stage of a single proc in the current codegen implementation. As with the single-proc case this bundling may cause problems such as deadlocks depending upon the expectations of the asynchronous system. The notion of a synchronous domain within an asynchronous system is not a new concept in XLS. Currently, a single proc within a proc network can be thought of as a synchronous domain (the nodes of the proc are synchronously scheduled) within an asynchronous domain (the proc network).
Broadcasting operations on channels
Although not currently in use or fully defined, broadcast operations where a single send communicates to multiple receives can be handled easily with synchronous procs if the channel is a feed-forward channel. Feed-forward channels become normal data flow edges with synchronous procs so a broadcast is treated identically to a node with multiple users.
[^1]The definition of forward and back edges may not be unique in a directed
graph because the categorization of edges depends on the DFS traversal order.
This suggests that unambiguous identification of feed-forward and loopback
channels may not be possible, however
[^2]This does not include procs with latency-sensitive behavior such as non-blocking receive operations.
[^3]The design could also be implemented as a small number of procs with most composition done using function invocation and the same arguments would apply.
[^4]One potential problem in PD is attribution of PPA problems. The hierarchy narrows down where the problems occur in the source code.
[^5]Though the send and receive may be in different procs with a synchronous system there is a notion of a global activation because all the iteration of all procs is coupled.
